Data Diagnostic Tools

Data Diagnostic Tools

Check if Subscriber is Active for Data

Determines if the subscriber's account is active for data, and if they are prepaid - if prepaid state is active and has a balance.

The Check if Subscriber is Active for Data tool determines if a subscriber's account is active for  data, and if they are prepaid - if the prepaid state is active and has a balance for data services.  Returns active for data, active-prepaid with data and the remaining data allowance, active prepaid but prepaid status not active, active prepaid but no remaining allowance for data, not active for data.

Tool Name

Tool Functionality

Inputs

Outputs

Example Prompt

check_if_active_for_data

  • Check that the subscriber status is Active for data
  • Check the subscriber prepaid status
  • Check the subscriber prepaid rate plan status
  • Check prepaid data balance

Subscriber number MSISDN number

Data status: active for data, active-prepaid with data and the remaining data allowance, active prepaid but prepaid status not active, active prepaid but no remaining allowance for data, not active for data

"Check if the subscriber is listed as active for data, and if they are prepaid, if prepaid is active and has a remaining allowance for data."

If they are active or active-prepaid, add "You may wish to ask the customer to check if they are having a problem with a specific URL / web site, or any / all web sites."

Check for Data Roaming

Determines if a subscriber's account has data roaming, domestic or international.

The Check for Data Roaming tool determine if a subscriber's account has data roaming, and if so, if the roaming includes domestic, international, or both.

Tool Name

Tool Functionality

Inputs

Outputs

Example Prompt

check_for_data_roaming

  • Check that the subscriber's account has data roaming
  • Check the type of data roaming (domestic, international or both)

Subscriber number MSISDN number

Data Roaming Domestic, Data Roaming International, Data Roaming Domestic and International, or No Data Roaming

"Check if the subscriber has data roaming and if the roaming includes domestic, international, or both."

Check Slow Data or Throttling

Determines why a subscriber is reporting slow data.

The Check 'Slow data or throttling' tool determines why a subscriber is reporting slow data or bandwidth throttling.

Tool Name

Tool Functionality

Inputs

Outputs

Example Prompt

check_slow_data_or_throttling

  • Check that the subscriber's prepaid rate plan status
  • Check that the subscriber's has at least 10% of their data capacity left in their prepaid data balance

Subscriber number MSISDN number

Report if they have a data plan, remaining capacity, capacity percentage, and if auto-refill is on

"Check if the subscriber has a prepaid data rate plan, auto-refill, and at least 10% remaining data capacity balance."

Check All of a Subscriber's Data Settings

Checks all the possible problems that may occur with a subscriber's data settings

The Check all of a subscriber's data settings tool determines if a subscriber's account has proper settings, any of which could block or cause problems with data service.  It checks active status, APN, IMSI, that the IMEI and ICCID / SIM id match, data roaming, prepaid, prepaid status, and prepaid data balance, registration status, and checks if the subscribers device is registered on the AT&T network, is compatible with the AT&T network, and is not blacklisted, and if the device is registered with an AT&T MVNO.  No additional MCP tools need to be called, the logic of this tool incorporates all those checks.

Tool Name

Tool Functionality

Inputs

Outputs

Example Prompt

check_all_data_settings_on_a_subscriber

  • Check Active Status
  • Check APN
  • Check IMSI
  • Check for Data Roaming
  • Check Registration Status
  • Check Device Compatibility with AT&T network
  • Check Device Not Blacklisted
  • Check if Device is on an AT&T MVNO provider
  • Check Prepaid Status - if YES, check Prepaid Rate Plan Status and check Prepaid Data Balance (report above or below 10%, and if auto-refill is on)

Subscriber number MSISDN number

Values of all settings listed under Tool Functionality

"Check if the subscriber has any settings that could block or cause problems with data service."
